16T-ES19: VANDAL-RESISTANT STAINLESS STEEL KEYPAD
Ergonomic 16-key numeric keypad with long-stroke keys, stainless steel keycaps and front panel. Backlit keycaps are available as an option.
- Designed for public areas with vandalism risk and extreme industrial environments
- Carbon contact technology
- High operating comfort with specially developed tactile long-stroke keys
- Stainless steel keycaps and front panel, with laser-etched key legends
- Custom key layouts and customer-specific adaptations are available on request
- Also available in a housing, with trackball or with a different number of keys
- Backlit keycaps are available as an option
Technical Specifications
The 16T-ES19 is a vandal-resistant 16-key numeric keypad for public areas and demanding industrial environments. Stainless steel keycaps and front panel, tactile long-stroke keys, and IP65/IK09 protection support reliable operation. Backlit keycaps are available as an option.
Product features
- Predestined for public areas with vandalism risk and industrial extreme environments
- Carbon contact technology
- High operating comfort thanks to our specially developed long-stroke keys
- Stainless steel keycaps and front panel
- Highly resistant to the effects of physical force
- Any key layout is possible
- Customer-specific adaptations can be implemented on request
- Also available in a housing, with a trackball or with a different number of keys
- Backlit keycaps are available as an option
Mechanical properties
- Dimensions: 4.37 × 4.37 × 1.54 in (111 × 111 × 39 mm)
- Key travel: 0.13 in (3.25 mm), with tactile feel
- Actuation force: 0.65 N
- 16 keys in compact layout
- Ergonomic 15 mm keycaps
- Durability > 10 million ops.
- Storage temperature: −40°F to +176°F (−40°C to +80°C)
- Operating temperature: −22°F to +140°F (−30°C to +60°C)
- Ingress protection: IP65; impact resistance: IK09
Electronic specifications
- Connection options: USB 2.0
- Power supply: +5 V/DC, 50 mA
- CE Compliant
- RoHS/Reach Compliant
Here's a closer look at the 16T-ES19:
Downloads
Want to dive deeper into the technical details? Download the 16T-ES19 datasheet for detailed specifications and product information.
Frequently Asked Questions (FAQ)
What is the 16T-ES19 designed for?
The 16T-ES19 is designed for public areas with a risk of vandalism and demanding industrial environments. Its stainless steel keycaps and front panel are highly resistant to physical force, and the keypad is rated IP65 and IK09.
What customization options are available for the 16T-ES19?
Any key layout is possible, and customer-specific adaptations can be implemented on request. The 16T-ES19 is also available in a housing, with a trackball or with a different number of keys.
Are backlit keycaps available for the 16T-ES19?
Yes. Backlit keycaps are available as an option. Contact PDS HMI to discuss the configuration for your application.
